Dell D825TM - 7 Electrical Parts List

— 31 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
D825TM
SECTION 7
ELECTRICAL PARTS LIST
RESISTORS
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF = µF
INDUCTORS
• UH = µH, MMH = mH
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
Note:
Les composants identifies per un trame
et une marque
¡¡
¡¡
¡ sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by [ in this manual
have been carefully factory-selected for each
set in order to satisfy regulations regarding X-
ray radiation. Should replacement be required,
replace only with the value originally used.
• Items marked " * " are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
REF.NO. PART NO. DESCRIPTION REMARK
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
When indicating parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
A
A
* A-1294-026-A A BOARD, COMPLETE
4-062-855-01 CASE, VIDEO
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C004 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C005 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C009 1-104-664-11 ELECT 47MF 20% 25V
C010 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C011 1-106-220-00 MYLAR 0.1MF 10% 100V
C012 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C013 1-128-528-11 ELECT 470MF 20% 16V
C014 1-128-562-11 ELECT 47MF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C018 1-107-652-11 ELECT 10MF 20% 200V
C019 1-137-399-11 FILM 0.1MF 5% 50V
C022 1-104-664-11 ELECT 47MF 20% 25V
C027 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C028 1-104-664-11 ELECT 47MF 20% 25V
C029 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C035 1-162-134-11 CERAMIC 470PF 10% 2KV
C042 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C044 1-164-344-11 CERAMIC CHIP 0.068MF 10% 25V
C046 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C047 1-104-664-11 ELECT 47MF 20% 25V
C048 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C049 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C050 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C051 1-104-664-11 ELECT 47MF 20% 25V
C053 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C054 1-137-528-11 FILM 0.1MF 10% 250V
C055 1-137-528-11 FILM 0.1MF 10% 250V
C090 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C092 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C101 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C102 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C104 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C105 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C106 1-137-528-11 FILM 0.1MF 10% 250V
C201 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C202 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C204 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C206 1-137-528-11 FILM 0.1MF 10% 250V
C301 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C302 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C304 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C305 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C306 1-137-528-11 FILM 0.1MF 10% 250V
CONNECTOR
CN301 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN302 1-695-915-11 TAB (CONTACT)
CN303 1-695-915-11 TAB (CONTACT)
CN305 1-564-511-11 PLUG, CONNECTOR 8P
CN306 * 1-564-509-11 PLUG, CONNECTOR 6P
CN307 * 1-564-512-11 PLUG, CONNECTOR 9P
CN309 * 1-564-510-11 PLUG, CONNECTOR 7P
CN310 * 1-564-507-11 PLUG, CONNECTOR 4P
CN311 * 1-564-506-11 PLUG, CONNECTOR 3P
DIODE
D001 8-719-109-89 DIODE RD5.6ESB2
D003 8-719-109-89 DIODE RD5.6ESB2
D005 8-719-911-19 DIODE 1SS119-25
D006 8-719-911-19 DIODE 1SS119-25
D007 8-719-109-89 DIODE RD5.6ESB2
