— 32 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
D825TM
Les composants identifies per un trame
et une marque
¡¡
¡¡
¡ sont critiques pour la
securite. Ne les remplacer que par une
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
A
D008 8-719-109-89 DIODE RD5.6ESB2
D014 8-719-911-19 DIODE 1SS119-25
D101 8-719-800-76 DIODE 1SS226
D104 8-719-970-83 DIODE HSS82
D105 8-719-970-83 DIODE HSS82
D106 8-719-970-83 DIODE HSS82
D201 8-719-800-76 DIODE 1SS226
D204 8-719-970-83 DIODE HSS82
D205 8-719-970-83 DIODE HSS82
D206 8-719-970-83 DIODE HSS82
D301 8-719-800-76 DIODE 1SS226
D304 8-719-970-83 DIODE HSS82
D305 8-719-970-83 DIODE HSS82
D306 8-719-970-83 DIODE HSS82
FERRITE BEAD
FB001 1-412-911-11 FERRITE
FB003 1-412-911-11 FERRITE
FB004 1-412-911-11 FERRITE
FB005 1-412-911-11 FERRITE
FB006 1-412-911-11 FERRITE
FB009 1-412-911-11 FERRITE
FB010 1-412-911-11 FERRITE
FB011 1-412-911-11 FERRITE
FB101 ¡ 1-216-295-91 SHORT
FB110 1-412-911-11 FERRITE
FB201¡ 1-216-295-91 SHORT
FB210 1-412-911-11 FERRITE
FB301¡ 1-216-295-91 SHORT
FB310 1-412-911-11 FERRITE
FILTER
FL001 1-421-928-11 FILTER, NOISE
FL002 1-412-911-11 FERRITE
FL101 1-414-793-21 FERRITE
FL201 1-414-793-21 FERRITE
FL301 1-414-793-21 FERRITE
IC
IC001 8-752-076-89 IC CXA2055P
IC002 8-759-435-33 IC LM2405T
IC003 8-759-478-65 IC CXD8688P
IC004 8-759-434-40 IC TDA6103Q/N3,112
IC005 8-759-100-96 IC UPC4558G2
IC006 8-752-082-65 IC CXA2093S
JACK
J001 ¡ 1-251-637-11 SOCKET, CRT
COIL
L002 1-410-682-31 INDUCTOR 470UH
L101 1-410-750-41 INDUCTOR 0.47UH
L201 1-410-750-41 INDUCTOR 0.47UH
L301 1-410-750-41 INDUCTOR 0.47UH
TRANSISTOR
Q001 8-729-032-61 TRANSISTOR 2SC5022-02
Q004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R002 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R003 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R004 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R005 1-216-113-00 RES,CHIP 470K 5% 1/10W
R006 1-216-025-91 RES,CHIP 100 5% 1/10W
R007 1-216-025-91 RES,CHIP 100 5% 1/10W
R014 1-216-025-91 RES,CHIP 100 5% 1/10W
R016 1-216-073-00 RES,CHIP 10K 5% 1/10W
R017 1-216-025-91 RES,CHIP 100 5% 1/10W
R018 1-216-025-91 RES,CHIP 100 5% 1/10W
R020 1-216-025-91 RES,CHIP 100 5% 1/10W
R021 1-216-025-91 RES,CHIP 100 5% 1/10W
R024 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R025 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R026 1-216-073-00 RES,CHIP 10K 5% 1/10W
R029 1-216-099-00 RES,CHIP 120K 5% 1/10W
R031 1-216-049-91 RES,CHIP 1K 5% 1/10W
R032 1-216-665-11 METAL CHIP 3.9K 0.50% 1/10W
R033 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R043 1-216-295-91 SHORT 0
R045 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R046 1-216-097-91 RES,CHIP 100K 5% 1/10W
R047 1-216-073-00 RES,CHIP 10K 5% 1/10W
R048 1-211-885-21 METAL 2.2M 5% 1W
R049 1-216-091-00 RES,CHIP 56K 5% 1/10W
R051 1-216-049-91 RES,CHIP 1K 5% 1/10W
R052 1-216-073-00 RES,CHIP 10K 5% 1/10W
R053 1-219-621-91 METAL 22M 10% 1/4W
R054 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R064 1-202-830-00 SOLID 10K 20% 1/2W
