Dell D825TM - Page 26

— 33 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
D825TM
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
D1
A
D1
R101 1-215-394-00 METAL 75 1% 1/4W
R104 1-216-037-00 RES,CHIP 330 5% 1/10W
R106 1-216-073-00 RES,CHIP 10K 5% 1/10W
R107 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R108 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R109 1-216-121-91 RES,CHIP 1M 5% 1/10W
R110 1-215-477-00 METAL 220K 1% 1/4W
R111 1-249-401-11 CARBON 47 5% 1/4W F
R112 1-216-037-00 RES,CHIP 330 5% 1/10W
R133 1-249-411-11 CARBON 330 5% 1/4W
R151 1-202-549-00 SOLID 100 20% 1/2W
R201 1-215-394-00 METAL 75 1% 1/4W
R204 1-216-037-00 RES,CHIP 330 5% 1/10W
R206 1-216-073-00 RES,CHIP 10K 5% 1/10W
R207 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R208 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R209 1-216-121-91 RES,CHIP 1M 5% 1/10W
R210 1-215-477-00 METAL 220K 1% 1/4W
R211 1-249-401-11 CARBON 47 5% 1/4W F
R212 1-216-037-00 RES,CHIP 330 5% 1/10W
R233 1-249-411-11 CARBON 330 5% 1/4W
R251 1-202-549-00 SOLID 100 20% 1/2W
R301 1-215-394-00 METAL 75 1% 1/4W
R304 1-216-037-00 RES,CHIP 330 5% 1/10W
R306 1-216-073-00 RES,CHIP 10K 5% 1/10W
R307 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R308 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R309 1-216-121-91 RES,CHIP 1M 5% 1/10W
R310 1-215-477-00 METAL 220K 1% 1/4W
R311 1-249-401-11 CARBON 47 5% 1/4W F
R312 1-216-037-00 RES,CHIP 330 5% 1/10W
R333 1-249-411-11 CARBON 330 5% 1/4W
R351 1-202-549-00 SOLID 100 20% 1/2W
SPARK GAP
SG001¡ 1-519-422-11 GAP, SPARK
SG101¡ 1-517-499-21 GAP, SPARK
SG201¡ 1-517-499-21 GAP, SPARK
SG301¡ 1-517-499-21 GAP, SPARK
* A-1343-447-A D-1 BOARD, MOUNTED
CAPACITOR
C1001 1-136-165-00 FILM 0.1MF 5% 50V
C1002 1-130-467-00 FILM 470PF 5% 50V
C1003 1-137-528-11 FILM 0.1MF 10% 250V
C1004 1-126-796-11 ELECT 22MF 20% 25V
CONNECTOR
CN1001* 1-564-508-11 PLUG, CONNECTOR 5P
CN1002 1-564-505-11 PLUG, CONNECTOR 2P
DIODE
D1001 8-719-970-83 DIODE HSS82
D1002 8-719-921-86 DIODE MTZJ-13
TRANSISTOR
Q1001 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
Q1002 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
Q1003 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1004 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
RESISTOR
R1001 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1002 1-249-430-11 CARBON 12K 5% 1/4W
R1003 1-249-421-11 CARBON 2.2K 5% 1/4W
R1004 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1005 1-249-435-11 CARBON 33K 5% 1/4W
R1006 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1007 1-249-429-11 CARBON 10K 5% 1/4W
R1008 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1009 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1010 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1011 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1012 1-216-037-00 RES,CHIP 330 5% 1/10W
