— 34 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
D825TM
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
D
* A-1346-704-A D BOARD, COMPLETE
1-533-223-11 CLIP, FUSE
4-051-602-11 SHEET, RADIATION
4-061-982-01 HOLDER, LED
4-382-854-11 SCREW (M3X10), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
CAPACITOR
C401 1-126-941-11 ELECT 470MF 20% 25V
C402 1-106-228-00 MYLAR 0.22MF 10% 100V
C403 1-126-969-11 ELECT 220MF 20% 50V
C404 1-126-941-11 ELECT 470MF 20% 25V
C405 1-137-372-11 FILM 0.022MF 5% 50V
C406 1-137-368-11 FILM 0.0047MF 5% 50V
C407 1-137-372-11 FILM 0.022MF 5% 50V
C501 1-126-964-11 ELECT 10MF 20% 50V
C502 1-137-370-11 FILM 0.01MF 5% 50V
C503 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C504 1-162-318-11 CERAMIC 0.001MF 10% 500V
C505 1-110-400-91 CERAMIC 27PF 5% 2KV
C506 1-126-960-11 ELECT 1MF 20% 50V
C507 1-115-517-11 FILM 0.39MF 5% 250V
C508 1-104-665-11 ELECT 100MF 20% 25V
C509 1-162-117-00 CERAMIC 100PF 10% 500V
C510 1-102-228-00 CERAMIC 470PF 10% 500V
C513 1-126-964-11 ELECT 10MF 20% 50V
C515 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C516 1-115-519-11 FILM 0.56MF 5% 250V
C517 1-137-370-11 FILM 0.01MF 5% 50V
C518 1-117-832-11 FILM 4700PF 3% 2KV
C519 1-136-538-11 FILM 0.001MF 3% 2KV
C520 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C521 1-107-444-11 CERAMIC 100PF 5% 2KV
C522 1-136-481-11 MYLAR 0.0022MF 10% 100V
C523 1-117-665-11 FILM 0.33MF 5% 200V
C524 1-107-955-11 ELECT 100MF 20% 200V
C525 1-115-511-11 FILM 0.12MF 5% 250V
C526 1-164-646-11 CERAMIC 2200PF 10% 500V
C527 1-117-879-91 CAPACITOR 0.01MF 10% 250V
C528 1-115-349-51 CERAMIC 0.01MF 2KV
C530 1-117-206-21 FILM 0.36MF 5% 250V
C532 1-137-426-11 FILM 0.47MF 10% 100V
C535 1-137-370-11 FILM 0.01MF 5% 50V
C536 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C539 1-137-418-11 FILM 0.022MF 10% 100V
C540 1-136-203-11 FILM 10000PF 5% 630V
C541 1-126-963-11 ELECT 4.7MF 20% 50V
C542 1-126-964-11 ELECT 10MF 20% 50V
C543 1-102-973-00 CERAMIC 100PF 5% 50V
C544 1-137-370-11 FILM 0.01MF 5% 50V
C545 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C546 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C547 1-126-960-11 ELECT 1MF 20% 50V
C548 1-137-364-11 FILM 0.001MF 5% 50V
C549 1-137-375-11 FILM 0.068MF 5% 50V
C550 1-126-933-11 ELECT 100MF 20% 16V
C551 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C552 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C553 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C554 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C555 1-137-399-11 FILM 0.1MF 5% 50V
C556 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C557 1-126-964-11 ELECT 10MF 20% 50V
C558 1-126-960-11 ELECT 1MF 20% 50V
C559 1-137-368-11 FILM 0.0047MF 5% 50V
C560 1-117-665-11 FILM 0.33MF 5% 200V
C561 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C562 1-126-933-11 ELECT 100MF 20% 16V
C563 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C570 1-104-665-11 ELECT 100MF 20% 25V
C573 1-107-635-11 ELECT 4.7MF 20% 160V
C574 1-117-879-91 CAPACITOR 0.01MF 10% 250V
C575 1-107-955-11 ELECT 100MF 20% 200V
C576 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C577 1-115-349-51 CERAMIC 0.01MF 2KV
C578 1-117-214-11 CERAMIC 0.001MF 10% 2KV
C579 1-109-842-11 CERAMIC 10PF 5% 2KV
C580 1-137-370-11 FILM 0.01MF 5% 50V
C601 ¡ 1-113-894-11 CERAMIC 100PF 10% 250V
C602 ¡ 1-113-912-11 CERAMIC 0.0047MF 20% 250V
C604 ¡ 1-104-708-11 FILM 0.47MF 20% 250V
C605 ¡ 1-107-533-11 FILM 1MF 20% 250V
C606 ¡ 1-113-912-11 CERAMIC 0.0047MF 20% 250V
C608 ¡ 1-113-894-11 CERAMIC 100PF 10% 250V
C610 1-109-984-11 ELECT(BLOCK) 390MF 20% 400V
C613 1-136-203-11 FILM 10000PF 5% 630V
C614 1-136-177-00 FILM 1MF 5% 50V
C615 1-137-364-11 FILM 0.001MF 5% 50V
C616 1-102-824-00 CERAMIC 470PF 5% 50V
C617 1-137-366-11 FILM 0.0022MF 5% 50V
C618 1-102-106-00 CERAMIC 100PF 10% 50V
