— 35 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
D825TM
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
C619 1-125-700-11 ELECT(BLOCK) 220MF 20% 200V
C620 1-107-933-11 ELECT 100MF 20% 100V
C621 1-126-942-61 ELECT 1000MF 20% 25V
C622 1-126-941-11 ELECT 470MF 20% 25V
C623 1-126-942-61 ELECT 1000MF 20% 25V
C624 1-126-935-11 ELECT 470MF 20% 16V
C625 1-137-399-11 FILM 0.1MF 5% 50V
C626 1-126-935-11 ELECT 470MF 20% 16V
C627 1-126-935-11 ELECT 470MF 20% 16V
C628 1-104-665-11 ELECT 100MF 20% 25V
C629 1-113-900-11 CERAMIC 470PF 10% 250V
C630 1-137-399-11 FILM 0.1MF 5% 50V
C632 1-126-935-11 ELECT 470MF 20% 16V
C633 1-126-935-11 ELECT 470MF 20% 16V
C634 1-126-940-11 ELECT 330MF 20% 25V
C635 1-137-370-11 FILM 0.01MF 5% 50V
C637 1-137-399-11 FILM 0.1MF 5% 50V
C640 1-113-912-11 CERAMIC 0.0047MF 20% 250V
C642 ¡ 1-113-912-11 CERAMIC 0.0047MF 20% 250V
C643 ¡ 1-113-912-11 CERAMIC 0.0047MF 20% 250V
C644 1-104-664-11 ELECT 47MF 20% 25V
C701 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C703 1-136-169-00 FILM 0.22MF 5% 50V
C704 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C705 1-137-399-11 FILM 0.1MF 5% 50V
C706 1-102-852-91 CERAMIC 47PF 5% 50V
C707 1-102-852-91 CERAMIC 47PF 5% 50V
C708 1-137-399-11 FILM 0.1MF 5% 50V
C709 1-126-941-11 ELECT 470MF 20% 25V
C710 1-126-941-11 ELECT 470MF 20% 25V
C711 1-137-399-11 FILM 0.1MF 5% 50V
C712 1-137-399-11 FILM 0.1MF 5% 50V
C713 1-126-927-11 ELECT 2200MF 20% 10V
C714 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C902 1-126-935-11 ELECT 470MF 20% 16V
C903 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C905 1-137-375-11 FILM 0.068MF 5% 50V
C906 1-136-177-00 FILM 1MF 5% 50V
C908 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C909 1-126-927-11 ELECT 2200MF 20% 10V
C910 1-137-399-11 FILM 0.1MF 5% 50V
C911 1-137-370-11 FILM 0.01MF 5% 50V
C912 1-126-933-11 ELECT 100MF 20% 16V
C913 1-137-399-11 FILM 0.1MF 5% 50V
C914 1-102-514-11 CERAMIC 22PF 5% 50V
C915 1-102-514-11 CERAMIC 22PF 5% 50V
C916 1-126-965-11 ELECT 22MF 20% 50V
C917 1-163-019-00 CERAMIC CHIP 0.0068MF 10% 50V
C918 1-126-964-11 ELECT 10MF 20% 50V
C920 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C921 1-126-935-11 ELECT 470MF 20% 16V
C922 1-126-960-11 ELECT 1MF 20% 50V
C923 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C924 1-126-965-11 ELECT 22MF 20% 50V
C925 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C926 1-126-935-11 ELECT 470MF 20% 16V
C927 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C928 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C929 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C930 1-137-370-11 FILM 0.01MF 5% 50V
C931 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C932 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C933 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C934 1-102-852-91 CERAMIC 47PF 5% 50V
C936 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CONNECTOR
CN501 * 1-580-798-11 CONNECTOR PIN (DY) 6P
CN502 * 1-564-512-11 PLUG, CONNECTOR 9P
CN511 1-695-915-11 TAB (CONTACT)
CN512 1-695-915-11 TAB (CONTACT)
CN600 ¡ 1-251-227-11 INLET, AC
CN601 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN602 * 1-506-371-00 PIN, CONNECTOR 2P
CN701 1-564-511-11 PLUG, CONNECTOR 8P
CN901 * 1-508-879-11 BASE POST 4P
CN902 1-564-513-11 PLUG, CONNECTOR 10P
CN903 * 1-564-510-11 PLUG, CONNECTOR 7P
DIODE
D401 8-719-979-58 DIODE EGP10D
D402 8-719-109-81 DIODE RD4.7ESB2
D403 8-719-911-19 DIODE 1SS119-25
D501 8-719-110-31 DIODE RD12ESB2
D502 8-719-975-77 DIODE SB340
D504 8-719-110-49 DIODE RD18ESB2
D505 8-719-941-74 DIODE ERB91-02
D506 8-719-061-21 DIODE FMQ-G5FMS
D507 8-719-109-85 DIODE RD5.1ESB2
D509 8-719-110-17 DIODE RD10ESB2
D510 8-719-018-82 DIODE RGP02-20EL-6394
D511 8-719-109-85 DIODE RD5.1ESB2
