— 36 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
D825TM
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
D512 8-719-911-19 DIODE 1SS119-25
D513 8-719-066-40 DIODE MUR160
D514 8-719-970-83 DIODE HSS82
D515 8-719-018-82 DIODE RGP02-20EL-6394
D516 8-719-051-97 DIODE 3DL41A(LC6-15)
D517 ¡ 8-719-110-67 DIODE RD27ESB2
D518 8-719-110-17 DIODE RD10ESB2
D520 8-719-018-82 DIODE RGP02-20EL-6394
D521 8-719-018-82 DIODE RGP02-20EL-6394
D522 8-719-911-19 DIODE 1SS119-25
D523 8-719-911-19 DIODE 1SS119-25
D524 8-719-970-83 DIODE HSS82
D525 8-719-970-83 DIODE HSS82
D527 8-719-109-85 DIODE RD5.1ESB2
D601 ¡ 8-719-025-88 DIODE GBU4JL-6088
D602 8-719-911-19 DIODE 1SS119-25
D605 8-719-911-19 DIODE 1SS119-25
D606 8-719-986-73 DIODE RB441Q
D607 8-719-053-19 DIODE UF4007G23
D608 8-719-110-49 DIODE RD18ESB2
D609 8-719-986-73 DIODE RB441Q
D610 8-719-979-58 DIODE EGP10D
D611 8-719-970-83 DIODE HSS82
D612 8-719-067-68 DIODE FMC-26UA
4-382-854-11 SCREW (M3X10), P, SW (+) (FOR D612)
D613 8-719-979-58 DIODE EGP10D
D614 8-719-058-38 DIODE FMN-G12S
D615 8-719-051-97 DIODE 3DL41A(LC6-15)
D616 8-719-979-84 DIODE EGP20DPKG23
D617 8-719-979-84 DIODE EGP20DPKG23
D618 8-719-979-84 DIODE EGP20DPKG23
D622 8-719-110-08 DIODE RD8.2ESB2
D624 8-719-911-19 DIODE 1SS119-25
D648 ¡ 8-719-110-36 DIODE RD13ESB2
D649 ¡ 8-719-991-33 DIODE 1SS133T-77
D654 8-719-109-60 DIODE RD2.7ESB2
D704 8-719-911-19 DIODE 1SS119-25
D901 8-719-911-19 DIODE 1SS119-25
D902 8-719-109-89 DIODE RD5.6ESB2
D905 8-719-911-19 DIODE 1SS119-25
D906 8-719-911-19 DIODE 1SS119-25
D907 8-719-911-19 DIODE 1SS119-25
D908 8-719-911-19 DIODE 1SS119-25
D909 8-719-109-89 DIODE RD5.6ESB2
D910 8-719-109-89 DIODE RD5.6ESB2
D912 8-719-045-19 DIODE SPB-26MVWF
D914 8-719-911-19 DIODE 1SS119-25
D916 8-719-911-19 DIODE 1SS119-25
D917 8-719-977-03 DIODE DTZ5.6B
D918 8-719-109-89 DIODE RD5.6ESB2
D919 8-719-109-89 DIODE RD5.6ESB2
D920 8-719-986-73 DIODE RB441Q
D922 8-719-404-49 DIODE MA111
D923 8-719-404-49 DIODE MA111
D924 8-719-404-49 DIODE MA111
D925 8-719-404-49 DIODE MA111
D931 8-719-158-15 DIODE RD5.6SB
D932 8-719-158-15 DIODE RD5.6SB
D933 8-719-158-15 DIODE RD5.6SB
D935 8-719-976-99 DIODE DTZ5.1B
FUSE
F601 ¡ 1-576-231-11 FUSE (H.B.C.) 4A/250V
FERRITE BEAD
FB502 1-410-396-41 FERRITE 0.45UH
FB504 1-412-911-11 FERRITE
FB506 1-412-911-11 FERRITE
FB601 1-410-396-41 FERRITE 0.45UH
FB602 1-410-396-41 FERRITE 0.45UH
FB603 1-412-911-11 FERRITE
FB604 1-412-911-11 FERRITE
FB605 1-412-911-11 FERRITE
FB606 1-412-911-11 FERRITE
FB608 ¡ 1-412-911-11 FERRITE
FB609 ¡ 1-412-911-11 FERRITE
FB610 ¡ 1-412-911-11 FERRITE
FB611 ¡ 1-412-911-11 FERRITE
FB612 ¡ 1-412-911-11 FERRITE
FB613 ¡ 1-412-911-11 FERRITE
FB614 ¡ 1-412-911-11 FERRITE
FB615 ¡ 1-412-911-11 FERRITE
FB616 1-412-911-11 FERRITE
FB902 1-247-807-31 CARBON 100 5% 1/4W
FB904 1-543-961-11 FERRITE
TERMINAL
GT001 * 1-537-738-21 TERMINAL, EARTH
GT002 * 1-537-738-21 TERMINAL, EARTH
