REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
D825TM
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
IC
IC401 8-759-444-83 IC LA7840L
4-382-854-11 SCREW (M3X10), P, SW (+) (FOR IC401)
IC501 ¡ 8-759-478-76 IC UPC5021-109
IC502 8-759-803-42 IC LA6500-FA
IC503 8-759-803-42 IC LA6500-FA
4-382-854-11 SCREW (M3X10), P, SW (+) (FOR IC503)
IC601 ¡ 8-759-482-46 IC MC44604
IC603 ¡ 8-749-012-59 IC MOC8105TV
IC604 ¡ 8-759-908-15 IC TL431CLP
IC605 ¡ 8-759-072-98 IC TDA8138A
4-382-854-11 SCREW (M3X10), P, SW (+) (IC605)
IC701 8-759-478-66 IC CXA8070P
IC702 8-749-014-32 IC STK392-910A
IC900 8-759-525-10 IC TC7SET08F(TE85L)
IC901 8-759-531-39 IC CXD8692S-CYR(OTP)
IC902 8-759-478-68 IC CXA8071P
IC904 8-759-165-81 IC PST600D-T
IC905 8-759-370-34 IC ST24C08FB6
CHIP CONDUCTOR
JR001 1-216-296-91 SHORT
JR002 1-216-296-91 SHORT
JR003 1-216-296-91 SHORT
JR004 1-216-296-91 SHORT
JR005 1-216-296-91 SHORT
JR006 1-216-296-91 SHORT
JR007 1-216-296-91 SHORT
JR008 1-216-296-91 SHORT
JR009 1-216-296-91 SHORT
JR010 1-216-296-91 SHORT
JR011 1-216-296-91 SHORT
JR013 1-216-296-91 SHORT
JR014 1-216-296-91 SHORT
JR015 1-216-296-91 SHORT
JR016 1-216-296-91 SHORT
JR017 1-216-296-91 SHORT
JR018 1-216-296-91 SHORT
JR019 1-216-296-91 SHORT
JR020 1-216-296-91 SHORT
JR021 1-216-296-91 SHORT
JR022 1-216-296-91 SHORT
JR023 1-216-296-91 SHORT
JR024 1-216-296-91 SHORT
JR025 1-216-296-91 SHORT
JR026 1-216-296-91 SHORT
JR027 1-216-296-91 SHORT
JR030 1-216-295-91 SHORT
COIL
L501 1-412-531-31 INDUCTOR 33UH
L502 1-412-531-31 INDUCTOR 33UH
L503 1-411-594-11 INDUCTOR
L506 1-412-550-11 INDUCTOR 1.2MMH
L508 1-409-896-11 COIL, HORIZONTAL LINEARITY
L510 1-416-367-11 COIL, HORIZONTAL CENTER
L603 1-412-537-31 INDUCTOR 100UH
L604 1-412-537-31 INDUCTOR 100UH
L605 1-406-665-11 INDUCTOR
L606 1-406-665-11 INDUCTOR
L901 1-412-537-31 INDUCTOR 100UH
L902 1-412-537-31 INDUCTOR 100UH
FILTER
LF602 ¡ 1-429-180-11 TRANSFORMER, LINE FILTER
TRANSISTOR
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q503 8-729-035-54 TRANSISTOR 2SJ449
4-382-854-11 SCREW (M3X10), P, SW (+) (FOR Q503)
Q504 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
Q505 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q506 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q507 8-729-041-29 TRANSISTOR BU2522AX-ON5008
4-382-854-11 SCREW (M3X10), P, SW (+) (FOR Q507)
Q508 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q510 8-729-042-42 TRANSISTOR 2SK2101-01MR-F141
4-382-854-11 SCREW (M3X10), P, SW (+) (FOR Q510)
Q511 ¡ 8-729-042-34 TRANSISTOR IRFU110A
Q512 8-729-041-93 TRANSISTOR IRLI530GLF33
Q513 8-729-041-93 TRANSISTOR IRLI530GLF33
Q515 8-729-041-93 TRANSISTOR IRLI530GLF33
Q517 8-729-326-11 TRANSISTOR 2SC2611
Q518 8-729-140-50 TRANSISTOR 2SC3209LK
Q520 8-729-042-23 TRANSISTOR IRFI9620GSLF35
Q521 8-729-119-76 TRANSISTOR 2SA1175-HFE
