Dell D825TM - Page 31

— 38 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
D825TM
REF.NO. PART NO. DESCRIPTION REMARK
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
Q601 8-729-029-92 TRANSISTOR DTC143ESA
Q602 ¡ 8-729-038-51 TRANSISTOR IRFIBC40G-LF38
4-382-854-11 SCREW (M3X10), P, SW (+) (FOR Q602)
Q604 ¡ 8-729-029-66 TRANSISTOR DTC114ESA
Q605 8-729-141-83 TRANSISTOR 2SB1094-LK
Q606 8-729-029-66 TRANSISTOR DTC114ESA
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q902 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q903 8-729-119-78 TRANSISTOR 2SC2785-HFE
RESISTOR
R401 1-249-383-11 CARBON 1.5 5% 1/4W F
R402 1-215-866-11 METAL OXIDE 330 5% 1W F
R403 1-214-798-21 METAL 1.8 1% 1/2W
R404 1-215-439-00 METAL 5.6K 1% 1/4W
R405 1-214-800-11 METAL 2.2 1% 1/2W
R406 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R407 1-249-425-11 CARBON 4.7K 5% 1/4W
R408 1-216-089-91 RES,CHIP 47K 5% 1/10W
R409 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R410 1-215-447-00 METAL 12K 1% 1/4W
R500 1-249-377-11 CARBON 0.47 5% 1/4W F
R501 1-247-807-31 CARBON 100 5% 1/4W
R502 1-216-103-00 RES,CHIP 180K 5% 1/10W
R503 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R504 1-249-377-11 CARBON 0.47 5% 1/4W F
R505 1-216-073-00 RES,CHIP 10K 5% 1/10W
R506 1-215-485-00 METAL 470K 1% 1/4W
R507 1-215-427-00 METAL 1.8K 1% 1/4W
R508 1-247-807-31 CARBON 100 5% 1/4W
R509 1-247-863-91 CARBON 22K 5% 1/4W
R510 1-216-081-00 RES,CHIP 22K 5% 1/10W
R511 1-249-381-11 CARBON 1 5% 1/4W F
R512 1-249-389-11 CARBON 4.7 5% 1/4W
R513 1-215-888-00 METAL OXIDE 220 5% 2W F
R514 1-216-081-00 RES,CHIP 22K 5% 1/10W
R516 9-910-999-31 METAL 150 1% 1/2W
R517 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R518 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R520 1-249-397-11 CARBON 22 5% 1/4W F
R521 1-249-417-11 CARBON 1K 5% 1/4W F
R522 1-249-401-11 CARBON 47 5% 1/4W
R523 1-216-089-91 RES,CHIP 47K 5% 1/10W
R524 1-216-089-91 RES,CHIP 47K 5% 1/10W
R525 1-249-417-11 CARBON 1K 5% 1/4W F
R526 1-249-425-11 CARBON 4.7K 5% 1/4W
R527 1-249-429-11 CARBON 10K 5% 1/4W
R528 1-247-863-91 CARBON 22K 5% 1/4W
R529 1-249-429-11 CARBON 10K 5% 1/4W F
R530 1-216-474-11 METAL OXIDE 82 5% 3W F
R531 1-216-474-11 METAL OXIDE 82 5% 3W F
R532 1-249-385-11 CARBON 2.2 5% 1/4W F
R533 1-249-417-11 CARBON 1K 5% 1/4W F
R534 1-249-405-11 CARBON 100 5% 1/4W F
R535 1-216-089-91 RES,CHIP 47K 5% 1/10W
R538 1-215-905-11 METAL OXIDE 10 5% 3W F
R539 1-215-905-11 METAL OXIDE 10 5% 3W F
R540 1-215-476-00 METAL 200K 1% 1/4W
R541 1-215-421-00 METAL 1K 1% 1/4W
R542 1-215-421-00 METAL 1K 1% 1/4W
R543 1-249-389-11 CARBON 4.7 5% 1/4W F
R544 1-215-493-00 METAL 1M 1% 1/4W
R545 ¡ 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R546 ¡ 1-215-457-00 METAL 33K 1% 1/4W
R547 ¡ 1-215-487-00 METAL 560K 1% 1/4W
R548 ¡ 1-216-657-11 METAL CHIP 1.8K 0.50% 1/10W
R549 ¡ 1-215-467-00 METAL 82K 1% 1/4W
R550 ¡ 1-215-427-00 METAL 1.8K 1% 1/4W
R551 1-215-457-00 METAL 33K 1% 1/4W
R552 ¡ 1-215-463-00 METAL 56K 1% 1/4W
R553 1-218-760-11 METAL CHIP 220K 0.50% 1/10W
R554 1-218-756-11 METAL CHIP 150K 0.50% 1/10W
R556 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R557 1-216-079-00 RES,CHIP 18K 5% 1/10W
R558 1-215-445-00 METAL 10K 1% 1/4W
R559 1-215-431-00 METAL 2.7K 1% 1/4W
R560 1-215-449-00 METAL 15K 1% 1/4W
R561 1-216-474-11 METAL OXIDE 82 5% 3W F
R562 1-215-447-00 METAL 12K 1% 1/4W
R563 1-249-383-11 CARBON 1.5 5% 1/4W F
R564 1-216-089-91 RES,CHIP 47K 5% 1/10W
R566 1-215-859-00 METAL OXIDE 22 5% 1W F
R567 1-216-073-00 RES,CHIP 10K 5% 1/10W
R568 1-249-437-11 CARBON 47K 5% 1/4W
R569 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R570 1-249-417-11 CARBON 1K 5% 1/4W
R571 1-215-926-00 METAL OXIDE 33K 5% 3W F
R572 1-249-437-11 CARBON 47K 5% 1/4W
R573 1-247-887-00 CARBON 220K 5% 1/4W
R577 1-215-889-00 METAL OXIDE 330 5% 2W F
R578 1-216-447-00 METAL OXIDE 27 5% 2W F
R579 1-247-883-00 CARBON 150K 5% 1/4W
R580 1-216-077-00 RES,CHIP 15K 5% 1/10W
R581 1-249-429-11 CARBON 10K 5% 1/4W
