Dell Dimension 3000 User Manual

Removing and Installing Parts 57
NOTICE: To prevent static damage to components inside your computer, discharge static electricity from your
body before you touch any of your computer’s electronic components. You can do so by touching an unpainted
metal surface on the computer chassis.
Your Dell™ computer provides three slots for PCI cards.
PCI Cards
If you are installing or replacing a card, follow the procedures in the next section. If you are removing but not
replacing a card, see "Removing a PCI Card" on page 59.
If you are replacing a card, remove the current driver for the card from the operating system.
Installing a PCI Card
1 Follow the procedures in "Before You Begin" on page 45.
2 Unscrew and remove the filler bracket for the card slot you want to use.
CAUTION: Some network adapters automatically start the computer when they are connected to a network. To
guard against electrical shock, be sure to unplug your computer from its electrical outlet before installing any
cards.
filler bracket
securing screw

Dell Dimension 3000 Specifications

General

RAM	256MB - 2GB DDR SDRAM
Graphics	Integrated Intel Extreme Graphics 2
Operating System	Windows XP Home or Professional
Chipset	Intel 865GV
Maximum Memory	2GB
Network	Integrated 10/100 Ethernet
Power Supply	250W
Processor	Intel Pentium 4
Storage	40GB IDE HDD
Optical Drive	CD-ROM
Audio	Integrated Audio
Ports	USB 2.0, serial, parallel
Expansion Slots	3 x PCI
Weight	Approx. 24 lbs
