About Your Dell™ E-Port Plus 5
1
About Your Dell™ E-Port Plus
The Dell™ E-Port Plus docking device supports the Dell E-Family laptop
computers, but is not compatible with any previous series laptop computers.
The E-Port Plus enables you to connect your laptop computer to the
following external devices:
Connector Description
RJ-45 NETWORK CONNECTOR Connects a network
interface cable.
PARALLEL CONNECTOR Connects a parallel device
such as a printer.
DOCKING CONNECTOR Connects the laptop to the
E-Port Plus docking device.
AUDIO CONNECTORS Connects audio headphones or
speakers and a microphone.
USB 2.0
CONNECTORS Connect up to five USB 2.0
compliant devices, such as a USB mouse. Three USB
connectors are on the left side, and two USB connectors
are on the back of the E-Port Plus.
AC
ADAPTER CONNECTOR Connects the AC adapter.
D
ISPLAYPORT CONNECTOR Connects external
monitors equipped with a DisplayPort interface (also
HDMI and DVI monitors via dongle; available at
dell.com).
DIGITAL VIDEO INTERFACE (DVI) CONNECTOR
Connects external monitors equipped with a digital
video interface.
