Dell E152FPc - Power Supply Requirements; Panel Specifications

DELL E152FPc
11
4.3 POWER SUPPLY REQUIREMENTS
4.3.1 INPUT REQUIREMENTS
AC INPUT VOLTAGE: 100V ~ 240V
AC INPUT FREQUENCY: 50 ~ 60 HZ
AC INPUT CURRENT: 1.5A MAX
INRUSH CURRENT: 50A MAX AT 220V
LEAKAGE CURRENT: 3.5 mA Max.
4.3.2 OUTPUT REQUIREMENTS
ITEM MIN. TYP. MAX. UNIT REMARK
Output voltage (12V) 11.4 12 12.6 V
Output current (12V) 0 1.5 2.0 A
Output voltage ( 5V) 4.75 5.0 5.25 V
Output current (5V) 0 1.5 2.0 A
Ripple & Noise (12V) 200 mV
Ripple & Noise (5V) 100 mV
4.4 PANEL SPECIFICATION
4.4.1 PANEL FEATURE
4.4.2 DISPLAY CHARACTERISTICS
