Dell E2009W - Assembly Block

Service Manual
22
3. Assembly Block
VESA release button*1
(P,Cross,M4*10,BLACK-NL)*4
LE20M9 ASSEMBLY BLOCK
(I,Cross,M3*4,Zn-Cc)*2
(CMO/SAM/AUO)
(P,Cross,W/WAS,M3*6,Zn-Cc)*
3
FFC-CABLE*1
(P,Cross,W/WAS,M3*6,Zn-Cc)*
2
(BOLT,#4-40,NI)*4
(P,cross,T.T-3*4,Zn)*1
PANEL ASSY*1
BACK COVER ASSY*1
keypad board*1
spring
*2
fix-plateL*1
slide*1
fix-plateR*1
Chassis*1
I/F board*1
Power board*1
panel*1
CHASSIS ASSY*1
STAND ASSY*1
kensington lock*1
Back cover*1
front bezel*1
logo plate*1
Button_Function *1
FRONT BEZEL ASSY*1
EMI clip*
FINAL ASSY*1
(P,cross,T.T-3*4,Zn)*1
Screw,P,Cross,
T,T-2*3,BLK*4
(B,Cross,W/WAS,M3*9,Zn-Cc)*1
(I,Cross,M3*6,Zn-Cc)*2
power LENS*1
support rubber*4
TAPE,ACE,85x20mm*1
Note: 1. The arrows point out the direction of assembly
