Service Manual
27
method as followe: plugging in the VGA/DVI cable, press “Menu” button to call out OSD Main Menu, Press “Plus
Key”to select“Other Settings Menu”then pop submenu and choose Factory reset.
Auto Color Balance (Automatically calibrate chip ADC parameter by using chip internal
DAC.)
5.1 If it is a new-built set, press “Auto/Plus” button to execute “Auto Color” at standard video pattern
5-MOSAIC
pattern
5.2 Please confirm the following steps to perform “Auto Color Balance”:
- Connect the VGA cable with the standard video pattern generator and display 5-MOSAIC pattern on the
monitor.
- Press “Power” button to power off the monitor.
- Press “Menu” and “Auto/Plus” buttons simultaneously; then press “Power” button to power on the
monitor.
- Press “Plus Key”, select“Other Settings Menu” ,then Press “Plus Key”and choose factory at bottom
- Set BurnIn Mode item to ON, then execute Auto Color item.
- After the “Auto Color Balance” process finished, go back to “Other Settings Menu”, and press “Factory Reset” to exit Factory
mode
Upgrade Firmware to Serial via Flash Cable by ISP_Tool V4.100.exe
7.1 Connect the monitor and PC follow Fig 11
