Dell E2009W - Page 39

Service Manual
38
120 414908100310R RES SMD (0805) 100KΩ F,RT,RoHS TA-I,UNIOHM,WALSIN,YAGEO, 3 PC R5,R22,R848,
130 414908953210R RES SMD (0805) 95.3KΩ F,RT RoHS TA-I,UNIOHM,WALSIN,YAGEO, 1 PC R16,
140 414908510210R RES SMD (0805) 51KΩ F,RT RoHS TA-I,UNIOHM,WALSIN,YAGEO, 2 PC R8,R18,
150 414908010550R RES SMD (0805) 1MΩ J,RT RoHS REV:A TA-I,UNIOHM,WALSIN,YAGEO, 2 PC R9,R10,
160 414908100210R RES SMD (0805) 10KΩ F,RT RoHS REV:A TA-I,UNIOHM,WALSIN,YAGEO, 8 PC R12,R13,R21,R23,R860,R884,R886,R887,
170 414908330310R RES SMD (0805) 330KΩ F,RT RoHS TA-I,UNIOHM,WALSIN,YAGEO, 1 PC R17,
180 414908100110R RES SMD (0805) 1KΩ F,RT RoHS REV:A TA-I,UNIOHM,WALSIN,YAGEO, 4 PC R20,R24,R30,R31,
190 414908047050R RES SMD (0805) 47Ω J,RT RoHS TA-I,UNIOHM,WALSIN,YAGEO, 2 PC R840,R844,
200 414904499310R RES SMD (1206) 499KΩ F,RT RoHS REV:A TA-I,UNIOHM,WALSIN,YAGEO, 6 PC R841,R842,R843,R850,R851,R852,
210 414904270210R RES SMD (1206) 27kΩ F,RT ROHS TA-I,UNIOHM,WALSIN,YAGEO, 3 PC R853,R854,R855,
220 414908100910R RES SMD(0805)10Ω F,RT ROHS TA-I,UNIOHM,WALSIN,YAGEO, 1 PC R856,
230 414908270010R RES SMD (0805) 270Ω F,RT RoHS TA-I,UNIOHM,WALSIN,YAGEO, 1 PC R857,
240 414908330110R RES SMD (0805) 3.3KΩ F,RT RoHS REV:A TA-I,UNIOHM,WALSIN,YAGEO, 1 PC R868,
250 414908390110R RES SMD (0805) 3.9KΩ F,RT RoHS TA-I,UNIOHM,WALSIN,YAGEO, 1 PC R872,
270 411023004021R DIO SN4148-LF 75V/0.15A SMD 1206 (FEC)Ro FRONTIER, 1 PC D841,
270 411020046090R DIO 1N4148W 75V/0.15A(PEC)RoHS SOD-123 PANJIT, 0 PC
270 411020046310R DIO 1N4148W-F 75V/0.15A(DIODES RoHS,SOD- DIODES, 0 PC
280 411020068020R DIO BAW56 70V SOT-23(FRONTIER)RoHS FRONTIER, 1 PC ZD1,
280 411020068090R DIO BAW56 75V SOT-23(PANJIT)RoHS PANJIT, 0 PC
280 411020068210R DIO BAW56 85V SOT-23(PHILIPS)RoHS PHILIPS, 0 PC
290 411020047410R DIO BAV70 70V SOT23(MITSUBISHI RoHS MITSUBISHI, 2 PC ZD2,ZD3,
290 411020047210R DIO BAV70 85V SOT23 (PHILIPS) RoHS PHILIPS, 0 PC
290 411020047090R DIO BAV70, 70V SOT-23(PEC) ROHS PANJIT, 0 PC
290 411020047020R DIO BAV70-LF, 70V SOT-23(FEC) ROHS FRONTIER, 0 PC
300 411131556950R ZENER 5.6V 0.5W BZT52C5V6-F,SO D123(DIOD DIODES, 2 PC ZD4,ZD5,
300 411121456950R ZENER 5.6V BZT52-C5V6 SOD-123(WILLAS)ROH WILLAS, 0 PC
300 411131056050R ZENER 5.6V 0.5W BZX79-C5V6 DO3 5(PHILIPS PHILIPS, 0 PC
300 411120956950R ZENER 5.6V 0.41W BZT52-C5V6,SO D123(PANJ PANJIT, 0 PC
310 411020026210R DIO BAV99 350mW 70V SOT-23(PHI RoHS PHILIPS, 2 PC ZD6,ZD7,
310 411020026390R DIO BAV99,SOT-23(INFINEON)RoHS INFINEON, 0 PC
310 411020026090R DIO BAV99 350mW 75V SOT-23(PEC RoHS PANJIT, 0 PC
310 411020026020R DIO BAV99-LF 350mW 70V SOT-23 (FEC)RoHS FRONTIER, 0 PC
320 410080003290R XSTR AP4575GM N&P SO-8(APEC)ROHS AP, 2 PC Q6,Q7,
320 410080003430R XSTR P5506NVG N&P SOP-8(NIKO-SEM)ROHS NIKO, 0 PC
330 410070010240R XSTR MMBT4401 NPN SOT23(FAIRCHILD)RoHS FAIRCHILD, 1 PC Q851,
330 410070010420R XSTR MMBT4401 NPN SOT23(PANJIT)RoHS PANJIT, 0 PC
330 410070010210R XSTR PMBT4401 NPN SOT23(PHILIPS)RoHS PHILIPS, 0 PC
340 412000628810R
IC LD7552BPS SOP8（Leadtrend)ROHS
LEADTREND, 1 PC U850,
350 412000654630R IC INL833GN SOP16(O2 MICRO)Rohs O2, 1 PC U1,
360 791711410800R PCBA,P/I BOARD W/O SPK,AI LE19E6-812 ROH 1PC
370 419312254070R C SMD(0805) X7R 2.2uF 16V K RoHS DARFON,MURATA,TDK,WALSIN,YAGEO, 1 PC C3,
2E+07
ITEM P/N Description Supplier Usage Un Location
791711410800R PCBA,P/I BOARD W/O SPK,AI LE19E6-812 ROH
10 791711450800R PCBA,P/I BOARD W/O SPK,AI/A LE19E6-812 R 1PC
20 791711460800R PCBA,P/I BOARD W/O SPK,AI/R LE19E6-812 R 1PC
2E+07
ITEM P/N Description Supplier Usage Un Location
791711450800R PCBA,P/I BOARD W/O SPK,AI/A LE19E6-812 R
10 411032006020R DIO FR10-10-LF 1000V/1A AT(FRO NTIER)RoH FRONTIER, 1 PC D851,
10 411032006040R DIO FR107 1000V/1A DO-41(MOSPE C)RoHS MOSPEC, 0 PC
10 411020053090R DIO PS1010R 1000V/1A DO-41(PAN JIT)RoHS PANJIT, 0 PC
20 411020064090R DIO ER104 400V/1A DO-41(PANJIT RoHS PANJIT, 1 PC D852,
20 411032001020R DIO SF10-04-LF 400V/1A DO-41(F RONTIER)R FRONTIER, 0 PC
30 415211009140R RES MF 1/8W 10Ω F,AT,RoHS QUEENMAO,TZAI YUAN,UNIOHM, 1 PC R7,
40 415212703140R RES MF 1/8W 270KΩ F,AT,RoHS QUEENMAO,TZAI YUAN,UNIOHM, 1 PC R871,
50 411131430010R ZENER 30V GDZ30A DO35(WILLAS)RoHS WILLAS, 1 PC ZD880,
50 411130930010R ZENER 30V GDZ30A DO35(PANJIT)RoHS PANJIT, 0 PC
60 430613050100R FUSE SLOW PICO II 5A/125V U/C,AT,ROHS LITTELFUSE, 1 PC F851,
60 430613050101R FUSE SLOW 5A/125V U/C,AT,ROHS WALTER, 0 PC
70 491531400800R PCB,P/I ,1/OSP /CEM1/16,LE19E6-812 ROHS HSIANGKUO,TATCHUN, 1 PC
