Replacing the solid-state drive
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
CAUTION: Solid-state drives are fragile. Exercise care when handling
the hard drive.
Procedure
1 Slide the solid-state drive into the solid-state drive slot.
2 Replace the screw that secures the solid-state drive to the system base.
3 Place the solid-state drive heat shield on the system board.
4 Replace the screws that secure the solid-state drive heat shield to the
system board.
Post-requisites
Replace the top cover.
