Removing the DIP switch
board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the top cover.
2 Remove the solid-state drive.
3 Remove the wireless card.
4 Remove the mobile broadband card.
5 Remove the base frame.
Procedure
1 Remove the screws that secure the DIP switch board assembly to the
status-light board.
34
