Replacing the status-light
board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Procedure
1 Place the status-light board. on the base frame
2 Replace the screws that secure the status-light board to the base frame.
Post-requisites
1 Replace the DIP switch board.
2 Replace the base frame.
3 Replace the mobile broadband card.
4 Replace the wireless card.
5 Replace the solid-state drive.
6 Replace the top cover.
39
