Table 4 LCD panel features
Item Button or
display
Description
1 Left Moves the cursor back in one-step increments.
2 Select Selects the menu item that is highlighted by the cursor.
3 Right Moves the cursor forward in one-step increments.
During message scrolling:
l
Press and hold the right button to increase scrolling speed.
l
Release the button to stop.
Note: The display stops scrolling when the button is released. After 45 seconds of inactivity, the
display starts scrolling.
4 LCD display Displays system information, status, and error messages or iDRAC IP address.
Viewing Home screen
The Home screen displays user-configurable information about the system. This screen is displayed during normal
system operation when there are no status messages or errors. When the system turns off and there are no errors,
LCD enters the standby mode after five minutes of inactivity. Press any button on the LCD to turn it on.
Procedure
1. To view the Home screen, press one of the three navigation buttons (Select, Left, or Right).
2. To navigate to the Home screen from another menu, complete the following steps:
a.
Press and hold the navigation button till the up arrow is displayed.
b.
Navigate to the Home icon using the up arrow .
c. Select the Home icon.
d. On the Home screen, press the Select button to enter the main menu.
Setup menu
The Setup menu contains the following options:
Note:
When you select an option in the Setup menu, you must confirm the option before proceeding to the next
action.
iDRAC
Select DHCP or Static IP to configure the network mode. If Static IP is selected, the available fields are IP,
Subnet (Sub), and Gateway (Gtw). Select Setup DNS to enable DNS and to view domain addresses. Two
separate DNS entries are available.
Set error
Select SEL to view LCD error messages in a format that matches the IPMI description in the SEL. This enables you
to match an LCD message with an SEL entry.
Select Simple to view LCD error messages in a simplified user-friendly description. For information about the
event and error messages generated by the system firmware and agents that monitor system components, see the
Error Code Lookup page at qrl.dell.com
VxFlex appliance and VxFlex Ready Node R740xd system overview
R740xd Owner's Guide 11
