Table 6 Back view features for the VxFlex Ready Node R740xd 4 x 2.5 inch drive system (continued)
Item Ports, panels, or slots Icon Description
2 Half-height PCIe expansion
card slot
N/A The PCIe expansion card slot (riser 2) connects one half-height
PCIe expansion cards to the system. For more information, see
Expansion bus specifications.
3 Rear handle N/A The rear handle can be removed to enable any external cabling of
PCIe cards that are installed in PCIe expansion card slot 6.
4 Rear disk drive (4) N/A This system supports 4 x 2.5 inch drives in the back of the
appliance.
5 Power supply unit (2) For more information, see Technical specifications
6 NIC ports The NIC ports that are integrated on the network daughter card
(NDC) provide network connectivity. For more information about
the supported configurations, see Technical specifications.
7 USB port (2) The USB ports are 9-pin and 3.0-compliant. These ports enable
you to connect USB devices to the system.
8 VGA port Enables you to connect a display device to the system. For more
information, see Technical specifications.
9 Serial port Enables you to connect a serial device to the system. For more
information, see Technical specifications.
10 iDRAC9 dedicated port Enables you to remotely access iDRAC. For more information, see
the
Integrated Dell Remote Access Controller User's Guide
at
www.dell.com/idracmanuals.
11 System identification
button
The System Identification (ID) button is available on the front and
back of the system. Press the system ID button to identify a
system in a rack. You can also use the system ID button to reset
iDRAC and access BIOS using step-through mode.
Inside the system
Internal components that are hot swappable are marked orange and touch points on the components are marked blue.
CAUTION
Many repairs may only be done by a certified service technician. You should only perform
troubleshooting and simple repairs as authorized in your product documentation, or as directed by the online or
telephone service and support team. Damage due to servicing that is not authorized by Dell EMC is not covered by
your warranty. Read and follow the safety instructions that are shipped with your product.
VxFlex appliance and VxFlex Ready Node R740xd system overview
14 R740xd Owner's Guide
