Figure 5 Cabinet stack up for a minimum configuration
Table 7 Maximum configuration in 3-phase wye power distribution cabinets
Component Function Description Quantity Cabinet U Space
Data Server R640 Server 32 2 - 17 and 25 - 36
Management Server Management Server 1 18
R640 Equipment Installation
28 Dell EMC VxFlex Ready Node Server Installation Guide
