Table 18 Data network A cabling (continued)
Data Network A
Node 11 Onboard Port 0 Data Network Switch A Port 5
Node 12 Onboard Port 0 Data Network Switch A Port 9
Node 13 Onboard Port 0 Data Network Switch A Port 13
Node 14 Onboard Port 0 Data Network Switch A Port 17
Node 15 Onboard Port 0 Data Network Switch A Port 21
Node 16 Onboard Port 0 Data Network Switch A Port 25
Node 17 Onboard Port 0 Data Network Switch A Port 29
Data network B wiring for R740XD servers
Use the following table to connect the data network B cables.
Table 19 Data network B cabling
Data Network B
Source Destination
Node 1 PCIe Port 2 Data Network Switch B Port 4
Node 2 PCIe Port 2 Data Network Switch B Port 8
Node 3 PCIe Port 2 Data Network Switch B Port 12
Node 4 PCIe Port 2 Data Network Switch B Port 16
Node 5 PCIe Port 2 Data Network Switch B Port 20
Node 6 PCIe Port 2 Data Network Switch B Port 24
Node 7 PCIe Port 2 Data Network Switch B Port 28
Node 8 PCIe Port 2 Data Network Switch B Port 32
Node 9 PCIe Port 2 Data Network Switch B Port 36
Management Server Port 1 Data Network Switch B Port 48
Node 10 PCIe Port 2 Data Network Switch B Port 3
Node 11 PCIe Port 2 Data Network Switch B Port 7
Node 12 PCIe Port 2 Data Network Switch B Port 11
Node 13 PCIe Port 2 Data Network Switch B Port 15
Node 14 PCIe Port 2 Data Network Switch B Port 19
Node 15 PCIe Port 2 Data Network Switch B Port 23
Node 16 PCIe Port 2 Data Network Switch B Port 27
Node 17 PCIe Port 2 Data Network Switch B Port 31
