Dell Force10 C150 Quick Start Guide

18 Installing the Hardware
Specifications
Chassis Physical Design
Environmental Parameters
AC Power Requirements
Parameter C150 Specifications C300 Specifications
Height 15.7 inches (39.88 cm) 22.7 inches (57.66 cm)
Width 17.5 inches (44.45 cm) 17.4 inches (37.58 cm)
Depth 15.3 inches (38.86 cm) 14.4 inches (44.20 cm)
Chassis weight 38 lbs (17.24 kg) with factory
installed components
86.63 lbs (39.29 kg) fully
loaded
55 lbs (24.95 kg) with factory
installed components
152.27 lbs (69.07 kg) fully
loaded
Parameter C150 Specifications C300 Specifications
Temperature 41° to 104°F (5°C to 40°C)
(storage temperature)
41° to 104°F (5°C to 40°C)
(storage temperature)
Maximum thermal
output
24,566 BTU/hour (for
100/120V and 200/240V)
4095 BTU/hour (for 100/120V
and 200/240V)
Relative humidity 5 to 95% (non-condensing) 5 to 95% (non-condensing)
Parameter C150 Specifications C300 Specifications
Nominal input voltage 100 - 240 V 50/60 Hz 100-240 VAC 50/60 Hz
Maximum AC Power
Supply Input Current
(Based on 1200 W
output for 100/120 V
and 200/240 V lines.)
14 A @ 100 V per AC Power
Supply
12 A @ 120 V per AC Power
Supply
7 A @ 200 V per AC Power
Supply
6 A @ 240 V per AC Power
Supply
14 A @ 100 V per AC Power
Supply
12 A @ 120 VAC per AC
Power Supply
7 A @ 200 VAC per AC Power
Supply
6 A @ 240 VAC per AC Power
Supply
Maximum System
Power Input
4.5 KVA @ 100/120 V
4.4 KVA @ 200/240 V
8.7 KVA @ 100/120 V
8.5 KVA @ 200/240 V
