8 Hardware Overview

System Status

You can view S4820T status information in several ways, including LEDs and

boot menu options. You can also view status information through the

command line interface (CLI) show commands and with simple network

management protocol (SNMP). For more information about these options,

refer to the FTOS Command Line Reference Guide and FTOS Configuration

Guide for the S4820T System.

As shown in

Figure 1-3

, the S4820T includes LED displays on both the I/O and

PSU side of the chassis.

Figure 1-3. Port LEDs

1 - Locator LED (Blue)

2 - Stack LED (Blue/Green)

3 - Temp LED (Red)

4 - Diag LED (Green)

5 - FAN LED (Green/Red)

6 - Link LED (Green/Amber)

7 - Activity LED (Blinking

Green)

System LED
