Dell Force10 S4820T System

Hardware Overview 7
Front Panel
Figure 1-2 shows the S4820T front panel.
Figure 1-2. S4820T Front Panel
The front panel includes:
• 48 fixed 10GBase-T and four fixed QSFP+ ports
• One USB 2.0 port
NOTE: The light emitting diodes (LEDs) display for System is on the front panel.
The fan and power status indicators are on the back panel.
QSFP+ Ports
USB 2.0 Port
10GBase-T Ports
