10 Installing the Hardware
As soon as the cable is connected between the Z9000 and the power source, the
chassis is powered-up; there is no on/off switch.
Fans
The Z9000 comes from the factory with 1 power supply and 4 fan modules
installed in the chassis. The fan modules are hot-swappable, if 2 or more fans are
installed and running.
The fan speed increases and decreases automatically based upon the system's
state and temperature. The switch never intentionally turns off the fans. Use the
show logging command to see the log messages.
Z9000 Specifications
Chassis Physical Design
Step Task
1 Remove the small plastic cover from the DC connectors.
2
Ensure that the power source is turned off. Do not attach the DC cable to
the DC connectors while the power source is on.
3
Attach the connectors to the PSUs, making sure that the connections are
secure.
4
Replace the plastic cover over the DC connectors.
Parameter Specifications
Height 3.48 inches (8.8 cm)
Width 17.32 inches (44.0 cm)
Depth 24.00 inches (61.00 cm)
Rack clearance required Front: 5-inches (12.7 cm)
Rear: 5-inches (12.7 cm)
Thermal dissipation 2654 BTH/h (270W)
