Dell Inspiron 1520 User Manual

About Your Computer 29
Right Side View
OPTICAL DRIVE — For more information about the optical drive, see "Using
Multimedia" on page 61.
EJECT BUTTON — Press the eject button to open the optical drive.
8-
IN-1 MEMORY CARD READER — Provides a fast and convenient way to view and
share digital photos, music, and videos stored on a memory card. The computer ships
with a plastic blank installed in the slot. The 8-in-1 memory card reader reads the
following digital memory cards:
• Secure Digital (SD) memory card
• SDIO card
• MultiMediaCard (MMC)
•Memory Stick
• Memory Stick PRO
• xD-Picture Card
• Hi Speed-SD
• Hi Density-SD
IEEE 1394 CONNECTOR — Connects devices supporting IEEE 1394 high-speed
transfer rates, such as some digital video cameras.
1 battery status light 2 hard drive activity light
3 power light 4 optical drive
5 eject button 6 8-in-1 memory card reader
7 IEEE 1394 connector 8 video connector (VGA)
9 network connector (RJ-45) 10 USB connectors (2)
4 6 7
910
85
1
2
3

Dell Inspiron 1520 Specifications

General

Battery	6-cell or 9-cell Lithium-Ion
Chipset	Intel PM965
Processor	Intel Core 2 Duo
Display	15.4 inch
Resolution	1280 x 800
RAM	Up to 4GB DDR2
Storage	80GB to 250GB HDD
Graphics	Intel GMA X3100 or NVIDIA GeForce 8400M GS
Operating System	Windows Vista
Optical Drive	DVD+/-RW
Wireless	802.11a/g/n
Ports	4 x USB 2.0, VGA, Ethernet
