Dell Inspiron 5570 User Manual

Removing the display hinges
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the optical drive (optional).
2 Remove the base cover.
3 Remove the wireless card.
4 Remove the display assembly.
5 Remove the display bezel.
6 Remove the display panel.
Procedure
1 Remove the eight screws (M2.5x2.5) that secure the hinges to the display back-
cover and antenna assembly.
2 Remove the two screws (M2x2) that secure the hinge brackets to the display
back-cover and antenna assembly.
113

Dell Inspiron 5570 Specifications

General

Wireless	802.11ac Wi-Fi
Bluetooth	Bluetooth 4.1
Processor	Intel Core i5-8250U
Display	15.6-inch FHD (1920 x 1080) Anti-Glare LED-Backlit Display
RAM	8GB DDR4
Storage	1TB HDD
Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Home
Battery	42WHr Battery, 3-Cell (Integrated)
Weight	4.41 lbs (2.0 kg)
Ports	2 x USB 3.1 Gen 1, 1 x USB 2.0, 1 x HDMI, 1 x SD Card Reader, 1 x Headphone/Microphone Combo
