Dell Inspiron 5570 User Manual

Replacing the display hinges
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the hinges and brackets with the screw holes on the
display back-cover and antenna assembly.
2 Replace the two screws (M2x2) that secure the hinges to the display back-
cover and antenna assembly.
3 Replace the eight screws (M2.5x2.5) that secure the hinges to the display back-
cover and antenna assembly .
Post-requisites
1 Replace the display panel.
2 Replace the display bezel.
3 Replace the display assembly.
4 Replace the wireless card.
5 Replace the base cover.
6 Replace the optical drive (optional).
115

Dell Inspiron 5570 Specifications

General

Wireless	802.11ac Wi-Fi
Bluetooth	Bluetooth 4.1
Processor	Intel Core i5-8250U
Display	15.6-inch FHD (1920 x 1080) Anti-Glare LED-Backlit Display
RAM	8GB DDR4
Storage	1TB HDD
Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Home
Battery	42WHr Battery, 3-Cell (Integrated)
Weight	4.41 lbs (2.0 kg)
Ports	2 x USB 3.1 Gen 1, 1 x USB 2.0, 1 x HDMI, 1 x SD Card Reader, 1 x Headphone/Microphone Combo
