Dell Inspiron 5570 User Manual

Removing the power button with
ngerprint reader
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
NOTE: Applicable only for computers that are shipped with ngerprint
reader.
Prerequisites
1 Remove the optical drive (optional).
2 Remove the base cover.
3 Remove the battery.
4 Remove the solid-state drive.
5 Remove the fan.
6 Remove the heat sink.
7 Remove the wireless card.
8 Remove the power-button board.
9 Remove the system board.
Procedure
1 Peel the ngerprint reader cable o the palm rest and keyboard assembly.
2 Remove the screw (M2x2) that secures the power button with ngerprint
reader to the palm rest and keyboard assembly.
3 Using a plastic scribe, release the ngerprint-reader board from the palm rest
and keyboard assembly.
95

Dell Inspiron 5570 Specifications

General

Wireless	802.11ac Wi-Fi
Bluetooth	Bluetooth 4.1
Processor	Intel Core i5-8250U
Display	15.6-inch FHD (1920 x 1080) Anti-Glare LED-Backlit Display
RAM	8GB DDR4
Storage	1TB HDD
Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Home
Battery	42WHr Battery, 3-Cell (Integrated)
Weight	4.41 lbs (2.0 kg)
Ports	2 x USB 3.1 Gen 1, 1 x USB 2.0, 1 x HDMI, 1 x SD Card Reader, 1 x Headphone/Microphone Combo
