Table 16. Power Management (continued)
Option Description
● Custom
If Custom Charge is selected, you can also configure Custom Charge Start and Custom Charge
Stop.
NOTE: All charging mode may not be available for all the batteries.
Post behavior
Table 17. POST Behavior
Option Description
Adapter Warnings
Allows you to enable or disable the system setup (BIOS) warning messages when you use certain
power adapters.
● Enable Adapter Warnings—Default
Numlock Enable
Allows you to enable or disable the Numlock function when the system boots.
● Enable Numlock—Default
Fn Lock Options
Allows you to let hot key combinations Fn + Esc toggle the primary behavior of F1–F12, between
their standard and secondary functions. If you disable this option, you cannot toggle dynamically
the primary behavior of these keys.
● Fn Lock—Default
Click one of the following options:
● Lock Mode Disable/Standard
● Lock Mode Enable/Secondary—Default
Fastboot
Allows you to speed up the boot process by bypassing some of the compatibility steps.
Click one of the following options:
● Minimal—Default
● Thorough
● Auto
Extended BIOS POST
Time
Allows you to create an additional preboot delay.
Click one of the following options:
● 0 seconds—Default
● 5 seconds
● 10 seconds
Full Screen Logo
Allows you to display full screen logo, if your image matches screen resolution.
● Enable Full Screen Logo
This option is not set by default.
Warnings and Errors
Allows you to select different options to either stop, prompt and wait for user input, continue
when warnings are detected but pause on errors, or continue when either warnings or errors are
detected during the POST process.
Click one of the following options:
● Prompt on Warnings and Errors—Default
● Continue on Warnings
● Continue on Warnings and Errors
System setup 105
