Dell Latitude E6510 - Removing the Bluetooth Card; Replacing the Bluetooth Card

Back to Contents Page
Bluetooth Card
Dell™Latitude™E6510ServiceManual
Removing the Bluetooth Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the access panel.
4. Remove the optical drive.
5. Remove the keyboard.
6. Remove the hinge covers.
7. Remove the palm rest assembly.
8. Remove the display assembly.
9. Remove the screw that secures the Bluetooth®card to the system board.
10. Disconnect the Bluetooth cable from its connector on the system board and remove the Bluetooth card from the computer.
11. Disconnect the Bluetooth cable from the Bluetooth card.
Replacing the Bluetooth Card
To replace the Bluetooth card, perform the above steps in reverse order.
Back to Contents Page


WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: YoumayneedtoinstallAdobe™FlashPlayer™fromAdobe.com in order to view the illustrations below.
