Dell Latitude E6510 - Removing the LED Cover; Replacing the LED Cover

Back to Contents Page
LED Cover
Dell™Latitude™E6510ServiceManual
Removing the LED Cover
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Press in on the LED cover release latches in the battery bay.
4. Turn the computer over, with the right side facing up and remove the LED cover from the computer.
Replacing the LED Cover
To replace the LED cover, perform the above steps in reverse order.
Back to Contents Page


WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: YoumayneedtoinstallAdobe™FlashPlayer™fromAdobe.com in order to view the illustrations below.
