Dell Latitude E6510 - Removing the Modem; Replacing the Modem

Back to Contents Page
Modem
Dell™Latitude™E6510ServiceManual
Removing the Modem
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the access panel.
4. Remove the screw that secures the modem to the computer.
5. Using the Mylar tab, gently lift the modem up.
6. Disconnect the modem cable from the modem and remove the modem from the computer.
Replacing the Modem
To replace the modem, perform the above steps in reverse order.
Back to Contents Page


WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: YoumayneedtoinstallAdobe™FlashPlayer™fromAdobe.com in order to view the illustrations below.
