Dell Latitude E6510 User Manual

Back to Contents Page
System Setup
DellPrecision™MobileWorkstationM4500ServiceManual
Overview
Entering System Setup
Boot Menu
Navigation Keystrokes
System Setup Menu Options

Overview
Use System Setup as follows:
l To change the system configuration information after you add, change, or remove any hardware in your computer
l To set or change a user-selectable option such as the user password
l To read the current amount of memory or set the type of hard drive installed
Before you use System Setup, it is recommended that you write down the System Setup screen information for future reference.
Entering System Setup
1. Turn on (or restart) your computer.
2. WhentheblueDELL™logoisdisplayed,press<F2>immediately.
Boot Menu
The Boot menu lists all the valid boot devices for your computer. Use the Boot menu to:
l Run diagnostics on your computer
l Enter system setup
l Change the boot sequence without changing the boot sequence permanently in the system setup.
To access the Boot menu:
1. Turn on (or restart) your computer.
2. WhentheblueDELL™logoisdisplayed,press<F12>immediately.
Navigation Keystrokes
Use the following keystrokes to navigate System Setup screens.
System Setup Menu Options
The following tables describe the menu options for the System Setup program.
CAUTION: Unless you are an expert computer user, do not change the settings for this program. Certain changes can cause your computer to work
incorrectly.
Navigation
Action
Keystroke(s)
Expand and collapse field
<Enter>, left- or right-arrow key, or +/–
Expand or collapse all fields
< >
Exit BIOS
<Esc>—Remain in Setup, Save/Exit, Discard/Exit
Change a setting
Left or right-arrow key
Select field to change
<Enter>
Cancel modification
<Esc>
Reset defaults
<Alt><F> or Load Defaults menu option
General
Option
Description
This section lists the primary hardware features of your computer. There are no configurable options in this section.
l System Information
¡ BIOS Version
¡ Service Tag
¡ Asset Tag
¡ Ownership Tag
l Memory Information

Dell Latitude E6510 Specifications

General

Bus type	DMI
Stepping	B1
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-720QM
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-700 Mobile Series
Processor socket	Socket 988
Processor threads	8
Processor codename	Clarksfield
Processing Die size	296 mm²
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	12
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	774 M
Motherboard chipset	Intel® QM57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	500 GB
Display diagonal	15.6 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Type	PC
Graphics card family	NVIDIA
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 2 GB
Discrete graphics card model	NVIDIA® NVS™ 3100M
Maximum graphics card memory	0.5 GB
Keyboard layout	AZERTY
Pointing device	Touchpad
Bluetooth version	2.0+EDR
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Processor code	SLBLY
Processor ARK ID	43122
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	253.3 mm
Width	374.3 mm
Weight	2510 g
Height (rear)	33.5 mm
Height (front)	27.1 mm
