Latitude ON Flash Card
Dell™Latitude™E6510ServiceManual
Removing the Latitude ON Flash Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the access panel.
4. RemovethescrewthatsecurestheLatitudeON™Flashcardtothesystemboard.
5. Slide the Latitude ON Flash card out of its connector on the system board.
Replacing the Latitude ON Flash Card
To replace the Latitude ON Flash card, perform the above steps in reverse order.
Back to Contents Page


WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: YoumayneedtoinstallAdobe™FlashPlayer™fromAdobe.com in order to view the illustrations below.
