Modem Port Plug
Dell™Latitude™E6510ServiceManual
Removing the Modem Port Plug
1. Follow the procedures in Before Working Inside Your Computer.
2. Insertapaperclipintothereleaseholeandremovethemodemportplugfromthecomputer.
Replacing the Modem Port Plug
To replace the modem port plug, slide the modem port plug back into the modem port.
Back to Contents Page


WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: YoumayneedtoinstallAdobe™FlashPlayer™fromAdobe.com in order to view the illustrations below.
