100 Appendix
www.dell.com | support.dell.com
Ports and Connectors (continued)
Internally accessible:
Primary IDE channel 40-pin connector on PCI local bus
Secondary IDE channel 40-pin connector on PCI local bus
Floppy drive (optional) 34-pin connector
Video
Video controller integrated Intel 3D Extreme Graphics
Audio
Audio controller integrated audio
Network
Network controller Integrated 10/100 Ethernet
Controls and Lights
Power control push button
Front-panel power light solid green for power-on state; blinking green for
standby state; amber (see page 46)
Hard-drive access light green
Power
DC power supply:
Wattage 200 W or 250 W
Heat dissipation 682 or 853 BTU (fully-loaded computer without
monitor)
Voltage (see page 10 for
important voltage setting information)
100 to 120 V at 60 Hz; 200 to 240 V at 50 Hz
Backup battery 3-V CR2032 coin cell
Physical
Height x Width x Depth 36.8 x 18.4 x 42.6 cm
(14.5 x 7.25 x 16.75 inches)
Weight 10.4 kg (23 lb)
