 Cable Guide
Dell™OptiPlex™FX160/160ServiceManual
Removing the Cable Guide
Replacing the Cable Guide
Removing the Cable Guide

1. Remove the screw that secures the cable guide to the system board.

2. Lift the guide out of the computer.
Replacing the Cable Guide

1. Align the cable guide screw hole with the hole on the system board.

2. Secure the cable guide to the system board with the screw.
.
