Dell OptiPlex 5060 Tower - Page 45

c. Connect the PSU cables to the connectors on the system board [1].
d. Route the PSU cables through the retention clips [2, 3, 4, 5].
e. Connect the PSU cable to the connector on the system board [6].
Removing and installing components
45
