Table 20. Displays
Feature Specification
Type 23-inch full-HD WLED
Maximum resolution 1920 x 1080
Refresh rate 60 Hz
Brightness Brightness up/down buttons
Operating angle 178 horizontal / 178 vertical
Pixel pitch 0.2652 mm
Controls on-screen controls
Table 21. Drives
Feature Specification
Hard drive one 2.5-inch SATA hard drive or one 2.5-inch SATA drive
with an adapter bracket
NOTE: It supports dual hard drive.
Optical drive (optional) one DVD-ROM SATA drive or DVD+/- RW SATA drive
Table 22. Ports and Connectors
Feature Specification
Audio:
• one line-out connector at rear
• one global headset port at side
Network adapter one RJ-45 connector
USB 2.0 (Front/Rear/Internal) 0(side)/2/3
USB 3.0 (Front/Rear/Internal) 2(side)/4/0
Video one display port
HDMI
• one 19-pin output port
• one 19-pin input port
Media card reader one 4-in-1 slot
Table 23. Power
Feature Specification
185 Watt PSU
Frequency 47 Hz — 63 Hz
Voltage 90 VAC — 264 VAC
Input current Maximum 2.6 A ( Low AC range)
58
