15. SATA0 connector (blue)
16. M.2 PCIe SSD connector
17. Thunderbolt header
18. PCIe x16 (Slot2)
19. PCIe x1 (Slot1/2)
20. Processor socket
21. Video connector
22. Type-C connector
The following images indicate the location of the system board and provide a visual representation of the removal procedure.
