1. Base cover 2. Battery
3. Speakers 4. Power button with optional finger-print reader
5. Touchpad 6. Touchpad bracket
7. Power adapter port 8. Solid state drive thermal plate
9. M.2 2280 Solid-state drive 10. Palmrest-keyboard assembly
11. Display assembly 12. Memory modules
13. Wireless card with bracket 14. I/O board
15. System board 16. Heat sink
17. Fan 18. I/O board FFC
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
Working inside your computer 37
