Table 30. Antenna-cable color scheme
Connectors on the
wireless card
Antenna-cable color Silkscreen marking
Auxiliary Black AUX ▲ (black triangle)
3. Place the wireless-card bracket on the wireless card.
4. Replace the screw (M2x3.5) that secures the wireless-card bracket to the system board.
Next steps
1. Install the base cover.
2. Install the SD card.
3. Follow the procedure in After working inside your computer.
Fan
Removing the fan
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
About this task
The following images indicate the location of the fan and provide a visual representation of the removal procedure.
54
Removing and installing Customer Replaceable Units (CRUs)
