2. Pry open from the outer edge of the bottom, left, right, and top sides of the bezel..
3. Lift and remove the display bezel from the display assembly.
NOTE:
DO NOT use a scribe or any other objects to pry up the display bezel as shown the images as the pressure
applied on the display panel by the scribe can damage the display panel.
Removing and installing Field Replaceable Units (FRUs) 99
