About Your Monitor │ 19
Mini DisplayPort Connector
Pin Number 20-pin Side of the Connected Signal Cable
1 GND
2 Hot Plug Detect
3 ML_Lane 3(n)
4 CONFIG1
5 ML_Lane 3(p)
6 CONFIG2
7 GND
8 GND
9 ML_Lane 2(n)
10 ML_Lane 0(n)
11 ML_Lane 2(p)
12 ML_Lane 0(p)
13 GND
14 GND
15 ML_Lane 1(n)
16 AUX CH(p)
17 ML_Lane 1(p)
18 AUX CH(n)
19 GND
20 DP_PWR
