24 │ Setting Up the Monitor
Setting Up the Monitor
Attaching the Stand
NOTE: The stand is detached when the monitor is shipped from the
factory.
NOTE: This is applicable for a monitor with a stand. When any other
stand is bought, please refer to the respective stand setup guide for the
set-up instructions.
CAUTION: Do not remove the monitor from the packaging box
before attaching the stand.
To attach the monitor stand:
1. Follow the instructions on the aps of carton to remove the stand from the top
cushion that secures it.
2. Insert the stand base blocks fully into the stand slot.
3. Lift the screw handle and turn the screw clockwise.
4. After fully tightening the screw, fold the screw handle at within the recess.
