Keyboard specifications
Table 7. Keyboard specifications
Features Specification
Number of keys
● 80 (U.S. and Canada)
● 81 (Europe)
● 84 (Japan)
Size Full sized
● X= 19.05 mm key pitch
● Y= 18.05 mm key pitch
Backlit keyboard
Easy enable/disable via hotkey <Fn+F10 Key> variable
brightness levels
Layout QWERTY
Battery
NOTE: 97 WHr battery is not available with the 2.5 inch drives.
Table 8. Battery specifications
Features Specifications
Type
● 56 WHr lithium-ion polymer 3 cell battery
● 97 WHr lithium-ion polymer 6 cell battery
Dimension 1. 56 WHr lithium-ion polymer
● Length: 223.2 mm (8.79 inch)
● Width: 71.8 mm (2.83 inch)
● Height: 7.2 mm (0.28 inch)
● Weight: 250.00 g (0.55 lb)
2. 97 WHr lithium-ion polymer
● Length: 332 mm (13.07 inch)
● Width: 96.0 mm (3.78 inch)
● Height: 7.7 mm (0.30 inch)
● Weight: 450.00 g (0.992 lb)
Weight (maximum) 450.00 g (0.992 lb)
Voltage
● 56 WHr - 11.4 VDC
● 97 WHr - 11.4 VDC
Life span 300 discharge/recharge cycles
Charging time when the computer is off (approximate) 4 hours
Operating time Varies depending on operating conditions and can significantly
reduce under certain power-intensive conditions
Temperature range: Operating 0°C to 35°C (32°F to 95°F)
Temperature range: Storage -40°C to 65°C (-40°F to 149°F)
12 Technology and components
