Dell P72F - Page 61

To Next Page

To Previous Page

11 Disconnect the speaker cable from the system board.

12 Remove the four screws (M2x3) that secure the fans to the system board.

13 Remove the three screws (M2.5x5) that secure the system board to the

computer base.
