COLOR MONITOR
SERVICE MANUAL
SPECIFICATIONS
17VC
CHASSIS
P792
US/Canada Model
Chassis No: SCC-L38C-A
Design and specifi cations are subject to change without notice.
P792
Self Diagnosis
Supported model
™
Picture tube 0.24 mm aperture grill pitch (center)
17 inches measured diagonally
90-degree defl ection
Video image area (16.1" maximum viewing image)
Approx. 328 X 242 mm (w/h)
(13 x 9
5/8
inches)
Resolution Horizontal: Max. 1600 dots
Vertical: Max. 1200 lines
Standard image area Approx. 312 x 234 mm (w/h)
(12
3/8
x 9
1/4
inches)
Input signal
Video Analog RGB (75 ohms typical)
0.7 Vp-p, Positive
Sync Separate HD/VD,
TTL Polarity Free
External Composite,
TTL Polarity Free
(2k ohms impedance)
Sync on Green
Power Consumption 120 W
Defl ection frequency Horizontal: 30 to 96 kHz
Vertical: 48 to 170 Hz
AC input voltage/current 120V, 60Hz, 1.7A
Dimensions 402 x 418 x 421 mm (w/h/d)
(15
7/8
x 16
1/2
x 16
5/8
inches)
Mass Approx. 19 kg (41 lb 14 oz.)
9-978-881-01
