Power consumption Screen Horizontal Vertical Power Recovery time Indicator
mode (video) sync signal sync signal consumption
1 Normal operation active yes yes < 120 W -- Green
2 Active-off (3rd mode) blank no* no* < 3 W Approx. 10 sec. Amber
3 Power-off -- -- -- 0 W (approx) -- Off
* In this mode, the signal will appear in one of three ways: The Horizontal Sync Signal alone off, the Vertical Sync Signal
alone off, or both signals off.
POWER MANAGEMENT
The power saving mode complies with the VESA Display Power Management Signaling standard. Each state of power management shall be activated
by the host computer terminating the appropriate sync signals. Blanking the video must precede termination of the sync signals. The elapsed time
counter shall also be controlled by the host computer. Reactivation of the monitor shall be accomplished from the host computer by re-establishing the
normal sync signal.
TIMING SPECIFICATION
SELF DIAGNOSIS FUNCTION
When a failure occurs, the STANDBY/TIMER lamp will fl ash a set number of times to indicate the possible cause of the problem. If there is more than
one error, the lamp will identify the fi rst of the problem areas.
1
2
3
4
Status
Area of Failure
LED Indication
Amber (0.5 second) / Off (0.5 second)
Amber (1.5 second) / Off (0.5 second)
Amber (0.5 second) / Off (1.5 second)
Amber (0.5 second) / Off (0.5 second)/
Green (0.5 second) / Off (0.5 second)
HV or +B
H Stop, V Stop or S Correction FET Failure
ABL
Failure 1
Failure 2
Failure 3
Aging/Self Test
Primary
Mode
MODE 1234 5 6 7 8 9 10 11
Resolution (H x V) 640x480 640x480 720x400 800x600 1024x768 1024x768 1280x1024 640x480 800x 600 1280x1024 1600x1200
Dot Clock (MHz) 25.175 36.000 28.321 56.250 78.750 94.500 157.500 31.500 49.500 135.000 202.500
HORIZONTAL
Hor. Freq. (kHz) 31.469 43.269 31.468 53.674 60.023 68.677 91.146 37.500 46.875 79.976 93.750
H-Total 31.778 23.111 31.779 18.631 16.660 14.561 10.971 26.667 21.333 12.504 10.667
H-Blanking 6.356 5.333 6.356 4.409 3.657 3.725 2.844 6.349 5.172 3.022 2.765
H-Front Porch 0.636 1.556 0.636 0.569 0.203 0.508 0.406 0.508 0.323 0.119 0.316
H-Sync. 3.813 1.556 3.178 1.138 1.219 1.016 1.016 2.032 1.616 1.067 0.948
H-Back Porch 1.907 2.222 2.542 2.702 2.235 2.201 1.422 3.810 3.232 1.837 1.501
H-Active 25.422 17.778 25.423 14.222 13.003 10.836 8.127 20.317 16.162 9.481 7.901
(µsec)
VERTICAL
Ver. Freq. (Hz) 59.940 85.008 70.084 85.061 75.029 84.997 85.024 75.000 75.000 75.025 75.000
V-Total 525 509 449 631 800 808 1072 500 625 1066 1250
V-Blanking 45 29 49 31 32 40 48 20 25 42 50
V-Front Porch 10 1 13 1 1 1 1 1 1 1 1
V-Sync. 2 3 2 3 3 3 3 3 3 3 3
V-Back Porch 33 25 34 27 28 36 44 16 21 38 46
V-Active 480 480 400 600 768 768 1024 480 600 1024 1200
(lines)
SYNC.
Int (G) NO NO NO NO NO NO NO NO NO NO NO
Ext (H/V)/Polarity YES -/- YES -/- YES -/+ YES +/+ YES +/+ YES +/+ YES +/+ YES -/- YES +/+ YES +/+ YES +/+
Ext (C/S)/Polarity NO NO NO NO NO NO NO NO NO NO NO
Int/Non Int NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT
